Multi-Agent Systems

✍️ Author: Remy

Multi-Agent Systems Research Report

1. Multi-Agent Systems Overview

  • Definition: What is an agent?
  • Concept clarification: Differences and connections between workflow and (multi-)agent systems

2. Design Patterns for Multi-Agent Systems

2.1 Fundamentals: From Workflow to Agents

  • How to distinguish and choose between workflow vs agent architecture
  • From simple to complex: Progressive construction methodology

2.2 Key Components of Multi-Agent Systems

  • Agents: Systems where LLMs can dynamically guide their own processes and tool usage, capable of autonomous control over task completion methods.

  • Environment: The external world in which agents operate, which agents can perceive and act upon. The environment can be a software world or physical spaces like factories, roads, power grids, etc.

  • Interactions: Agents communicate through standardized communication languages. Depending on system requirements, interactions between agents include various forms such as cooperation, coordination, negotiation, etc.

  • Organization: Agents can be organized through hierarchical control or self-organize based on emergent behavior.

3. Key Modules

3.1 Basic Components

  • Multi-Agent System Structures:

    • Equi-Level Structure: Studies agent systems operating at the same level, such as DMAS (Chen et al., 2023).

    • Hierarchical Structure: Explores hierarchical structures with leader and follower roles, such as Stackelberg games (Von Stackelberg, 2010; Conitzer & Sandholm, 2006; Harris et al., 2023).

    • Nested Structure: Studies nested or hybrid structures, such as (Chan et al., 2023).

    • Dynamic Structure: Discusses dynamic structures of multi-agent systems, such as (Talebirad & Nadiri, 2023).

  • Planning:

    • Global Planning: Involves understanding overall tasks and decomposing tasks into subtasks, as well as coordinating workflows between agents.

    • Single-Agent Task Decomposition: Within individual agents, task decomposition involves breaking down large tasks into a series of manageable small tasks.

  • Memory/Context Management:

    • Short-term Memory: Immediate, temporary memory used during conversations or interactions.

    • Long-term Memory: Memory that stores historical conversations and responses.

    • External Data Storage: Such as RAG (Lewis et al., 2020), used for supplementary information sources.

    • Episodic Memory: Memory involving a series of interactions in multi-agent systems.

    • Consensus Memory: In multi-agent systems, serves as a unified source of shared information.

[cite] LLM Multi-Agent Systems: Challenges and Open Problems

3.2 Framework Selection

  • Key considerations for framework selection: when to use, when to avoid
  • Introduction to existing general frameworks: langgraph, autogen, swarm
  • Selection recommendations

3.3 Interaction Design for Multi-Agent Applications

  • Interaction design principles:

    • Task-oriented: Multi-agent applications should customize optimal interaction interfaces for each task, conforming to workflow design rather than using chat windows for everything.
    • Detail abstraction: Users don’t need to understand internal implementation details of agents, only their external behavior and interaction methods
    • Simple interaction: Interactions between users and agents should be as simple as possible, avoiding complex operational procedures
    • Adequate feedback: Agent behavior and decision-making processes should have clear feedback
    • Controllability: Users should be able to intervene and adjust agent behavior
  • Typical product case analysis:

    • Multi-agent applications (code development): cline, devin, cursor agent
    • Multi-agent applications (writing): deep researcher
    • Multi-agent building platforms: coze, langgraph studio

3.4 Evaluation Methods, Datasets, and Metrics

  • Benchmarks

    • Public benchmarks:
      • ToolBench: GitHub - OpenBMB/ToolBench: [ICLR’24 spotlight] An open platform for training, serving, and evaluation Large-scale tool calling instruction dataset supporting multi-step reasoning and real API integration
      • SWE-bench: https://github.com/princeton-nlp/SWE-bench Benchmark for evaluating LLM’s ability to solve GitHub issues, containing 2,294 Python code fixing tasks
      • Mind2Web: https://huggingface.co/datasets/osunlp/Mind2Web General web interaction dataset covering diverse DOM operations and user trajectories
      • WebArena: GitHub - web-arena-x/webarena: Code repo for “WebArena: A Realistic Web Environment for Building Autonomous Agents” Real web environment testing platform integrating 4 applications and tool libraries
      • AgentInstruct: https://huggingface.co/datasets/THUDM/AgentInstruct High-quality agent instruction dataset enhancing model task generalization capabilities
  • Evaluation Metrics

    • Performance Metrics

      • Task Resolution Rate (% Resolved)

        • Core performance indicator reflecting system’s problem-solving capability
      • Localization Accuracy (F1 Score)

        • Balance of precision and recall for code defect localization
      • Visual Necessity Impact

        • Improvement in task resolution rate from image input
      • Image Type Sensitivity

        • Adaptability to different image types (code screenshots/UI images/charts)
      • Code Modification Complexity (Patch Complexity)

        • Scale of reference solution modifications (number of files/lines/functions)
      • Task Difficulty Distribution

        • Proportion of tasks with different time requirements (simple/medium/difficult/extremely difficult)
      • Task Success Rate

        • Reference: https://www.restack.io/p/multi-agent-systems-answer-llm-evaluation-cat-ai
        • This metric measures the percentage of tasks successfully completed by agents, directly indicating overall efficiency.
        • Formula: Task Success Rate=Number of Successfully Completed TasksTotal Number of Tasks×100%\text{Task Success Rate} = \frac{\text{Number of Successfully Completed Tasks}}{\text{Total Number of Tasks}} \times 100\%
      • Collaboration Efficiency

      • Task Allocation Accuracy

        • Reference: https://www.restack.io/p/multi-agent-systems-answer-llm-evaluation-cat-ai
        • Whether tasks are assigned to the most suitable agents
        • Formula: Task Allocation Accuracy=Number of Correctly Allocated TasksTotal Number of Tasks×100%\text{Task Allocation Accuracy} = \frac{\text{Number of Correctly Allocated Tasks}}{\text{Total Number of Tasks}} \times 100\%
      • Task Completion Accuracy

        • Reference: https://www.restack.io/p/multi-agent-systems-answer-llm-evaluation-cat-ai
        • Accuracy of output results
        • Formula: Task Completion Accuracy=Number of Correct Output ResultsTotal Number of Completed Tasks×100%\text{Task Completion Accuracy} = \frac{\text{Number of Correct Output Results}}{\text{Total Number of Completed Tasks}} \times 100\%
      • Output Coherence

      • Progress Rate

        • Reference: AgentBoard https://arxiv.org/pdf/2401.13178
        • Continuous metric calculated through sub-goal matching or state similarity, reflecting gradual progress during task completion (0 to 1)
        • Formula:
          • Continuous tasks (such as state matching): rtmatch=max⁥0≤i≤tf(si,g)r_t^{\text{match}} = \max_{0 \leq i \leq t} f(s_i, g) where f(si,g)f(s_i, g) is the similarity function between current state sis_i and target state gg (such as table cell matching ratio).

          • Discrete sub-goal tasks (such as multi-step planning): rtsubgoal=max⁥0≤i≤t1K∑k=1Kf(si,gk)r_t^{\text{subgoal}} = \max_{0 \leq i \leq t} \frac{1}{K} \sum_{k=1}^K f(s_i, g_k) where gkg_k is the manually annotated kk-th sub-goal, and f(si,gk)∈{0,1}f(s_i, g_k) \in \{0,1\} indicates whether the sub-goal is completed.

    • Efficiency Metrics

      • Average Cost (Avg. Cost)
        • Economic cost of single-task inference
      • Abnormal Termination Rate
        • Proportion of task interruptions due to cost overruns or errors (reflecting resource waste)
      • Communication Latency: Agent response time (milliseconds)
      • Task Completion Time
    • Scalability Metrics

      • Multi-file Type Editing
        • Proportion of tasks that simultaneously modify multiple file types (TS/HTML/CSS)
      • Language Adaptability Comparison
        • Resolution rate degradation of Python-centric systems in JavaScript tasks
    • Reliability Metrics

      • Test Consistency
        • Consistency of the same patch passing multiple runs
      • Error Recovery Capability
        • Effectiveness of automatic retry or rollback mechanisms after task termination

4. Application Domains

4.1 Characteristics and Applicable Scenarios of Multi-Agent Systems

  • Characteristics of multi-agent systems: Non-real-time, non-deterministic
  • Suitable scenarios for multi-agent systems: Offline operations, error tolerance, high user tolerance and willingness to intervene
  • When (and when not) to use multi-agent systems

4.2 Typical Applications of Multi-Agent Systems in Banking Scenarios

  • Customer service robots: From knowledge operations to intelligent customer service
  • Intelligent writing: Simple copywriting, research report style, marketing copywriting style
  • Intelligent marketing: From customer profiling to precision marketing

5. References
